Description
KEY FEATURES
Thrust-Enhancing Reverse Exhaust: For more control at lower speeds and increased precision of our Helm Master® EX boat control system, exhaust is diverted away from the propeller at RPMs below 2,500.
Pump Stop Power Tilt Limit: The tilt pump shuts off when it reaches maximum tilt setting, rather than continuing to run, saving power and reducing noise at full trim in/out.
Wide-Span Mounting System: For minimized vibration and a more compact design, incredibly strong upper motor mounts placed wide on the exterior of the upper mid-section work in conjunction with our Long Span Mounting System.
Phase Angle Control Charging: The XTO’s NEW Phase Angle Control Charging System meets the extreme electrical needs of today’s larger boats. This Innovation Award-winning new system produces up to 96 amps of net charging power at idle—from a single outboard—and up to 480 net amps in a quint configuration. This is up to 65 percent more maximum net charge at idle than the previous XTO model.
Motor Specifications
-
- Engine Type: Yamaha XF425USB XTO Offshore Four Stroke
- Horsepower: 425hp
- Cylinders: 8 cyl
- Shaft Length: 30″ XX-Long
- Throttle/Shift: Digital Electronic Controls
- Steering: Integrated Electric Power Steering
- Starter: Electric
- Weight: 977 lbs
- Alternator Output: 100 amp
- Degree of Tilt: -4° through +73°
- Degree of Trim: -4° through +16°
- Full Throttle Range: 5000 – 6000 rpm
- Displacement: 5.6L
- Fuel Induction System: Direct Injection / Up to 2900 PSI
- Warranty: Yamaha 3-Year Warranty
Standard Features
-
- Power Trim & Tilt
- Dual Flush System
- Owner’s Manual
